CFWT240S232 – 550L Vertical Water Tank

This 550L vertical water tank is designed for easy access through doorways, making it perfect for rural waterline applications. Crafted in Western Canada using FDA-approved polyethylene with UV stabilizers, this product sets the standard for quality and longevity.

Volume:

545 liters, 144 US gallons, 120 IMP gallons

Measurements:

Height – 59.5inches(1511mm) x Diameter – 29inches(737mm)

Standard Features

• One piece construction
• 8” lid with 2” breather
• 1 inch bulkhead

Optional Features

• Optional stand

10 Year Warranty!

Installation Requirements

Foundation Preparation

A properly prepared foundation is essential for the long-term performance of the water tank.

Recommended Base

• Install the tank on a solid, level, fully supported foundation.
• Suitable foundation materials include:
  • Reinforced concrete pad
  • Compacted crushed gravel with a concrete paver
  • Engineered tank stand designed for the tank
• The entire bottom of the tank should be uniformly supported.
• The foundation should extend beyond the tank footprint where practical to provide stability.

Avoid

• Uneven ground
• Soft soil
• Sand without compaction
• Wooden pallets
• Loose bricks or blocks
• Surfaces that may settle unevenly over time

Tank Positioning

Proper positioning improves accessibility and protects the tank.

Installation Recommendations

• Install the tank in a vertical position only.
• Position the tank on a level surface.
• Ensure adequate clearance around the tank for maintenance and plumbing connections.
• Place the tank where the lid can be easily opened for inspection and cleaning.
• If installed outdoors, ensure the location provides proper drainage around the base.

Doorway Access

The slim profile allows the tank to pass through many standard residential doorways, making it suitable for:

• Utility rooms
• Garages
• Basements (where access permits)
• Pump rooms
• Rural water system installations

Inlet Connection

The inlet pipe should provide a controlled flow into the tank.

Recommendations include:

• Secure all plumbing to prevent excessive stress on the tank fittings.
• Use appropriately sized piping compatible with the intended application.
• Support external pipework independently of the tank.
• Install isolation valves where maintenance access is required.
• Avoid overtightening threaded fittings.

Outlet Connection

The tank includes a 1-inch bulkhead fitting.

Installation recommendations:

• Connect compatible 1-inch plumbing to the bulkhead fitting.
• Use thread sealant suitable for potable water applications if applicable.
• Support downstream piping independently.
• Install a shut-off valve downstream of the outlet for servicing.
• Inspect the bulkhead fitting after filling the tank to verify a watertight seal.

Overflow Installation

Although an overflow fitting is not supplied in the provided specifications, an overflow is recommended where appropriate.

Best practices include:

• Route overflow water away from building foundations.
• Discharge overflow to:
  • Storm drainage
  • Soakaway
  • Infiltration system
  • Approved drainage location
• Ensure the overflow cannot become blocked.
• Install screens where necessary to prevent insects or pests from entering the system.

Ventilation

The tank includes an:

• 8-inch access lid
• 2-inch integrated breather

Ensure:

• The breather remains unobstructed.
• Air can freely enter and leave the tank during filling and draining.
• The lid remains securely fastened after inspection.

Maintenance Access

Provide sufficient clearance around the tank for routine servicing.

Recommended minimum clearances:

Easy access allows:

• Interior cleaning
• Lid removal
• Plumbing inspection
• Bulkhead maintenance
• Leak detection

Safety Recommendations

For safe installation and operation:

• Install only on a fully supported foundation.
• Never allow the tank to hang from attached pipework.
• Do not use the tank to support plumbing or other equipment.
• Protect the tank from vehicle impact where applicable.
• Do not climb or stand on the tank.
• Keep the access lid securely closed when not servicing the tank.
• Follow local plumbing and building codes.
• When storing potable water, maintain appropriate sanitary practices.

General Installation Best Practices

• Verify the foundation is level before positioning the tank.
• Inspect the tank for shipping damage before installation.
• Confirm all fittings are properly tightened before filling.
• Fill the tank gradually while checking all plumbing connections.
• Inspect for leaks during the initial fill.
• Periodically inspect UV exposure, fittings, and support conditions.
• Clean the tank periodically based on water quality and intended use.
• If using the optional tank stand, ensure it is installed according to the manufacturer’s recommendations and is capable of supporting the fully loaded tank.

Routine Maintenance

Installation Summary
