DAB Simple inline Jet Pump

Description

Simple inline Jet Pump

TECHNICAL DATA:

💧 Operating Range: From 2 to 46gpm with a head up to 203ft ( 88 psi )
💧 Liquid quality requirements: clean, free from solids or abrasive substances, non-viscous, non-aggressive, non-crystallized, chemically neutral, close to the characteristics of water
💧 Liquid temperature Range: From 32°F to 95°F for domestic use or 32°F to 120°F for other uses.
💧 Maximum Suction depth: 26 ft
💧 Maximum ambient temp. 104°F
💧 Maximum operating pressure: 118 psi
💧 Installation: fixed or portable in a horizontal position
💧 Special version: on request other voltages and/or frequencies
💧 Power Supply: – 115-230v 60Hz Dual Voltage for JET 50 -75 – 100
💧 230v 60Hz for JET 150 – 200 – 300

Features:

💧 Wide and comprehensive range
💧 Availability of pump body and motor support in cast iron
💧 Internal ejector
💧 Design of fan guard to also function as air conveyor
💧 Interchangeable pump body

Advantages:

💧 Ability also to handle water containing gas
💧 the Simple inline jet pump has a Very high suction capacity
💧 Structure strength and flexibility
💧 Head up to 62 metres
💧 Optimal motor cooling

Benefits:

💧Ability to operate also in the presence of air bubbles and small quantities of sand

Reliable:

💧 Adaptable to specific requirements
💧 Prevention of malfunctions and maintenance of motor efficiency
💧 Standardization of components enables optimal spare parts management
