DAB Simple Inline Jet Pump Stainless

Simple inlet jet stainless is a Self-priming centrifugal pump for domestic use, also able to run in the presence of air bubbles, with stainless steel body. Optimal for small-medium irrigation systems and gardening applications.

SKU: 8059893172785 Category: Tags: , ,

$882.70

Description

Simple inlet Jet Stainless

TECHNICAL DATA

💧 Operating Range: From 2 to 21 gpm with a head up to 203ft ( 88 psi )
💧 Liquid quality requirements: clean, free from solids or abrasive substances, non-viscous, non-aggressive, non-crystallized, chemically neutral, close to the characteristics of water
💧 Liquid temperature Range: From 32°F to 95°F for domestic use or 32°F to 120°F for other uses.
💧 Maximum Suction depth: 26 ft
💧 Maximum ambient temp. 104°F
💧 Maximum operating pressure: 118 psi
💧 Installation: fixed or portable in a horizontal position
💧 Special version: on request other voltages and/or frequencies
💧 Power Supply: 115-230v 60Hz Dual Voltage

Features:

💧 Simple inlet jet stainless self-priming centrifugal electric pump
💧 Stainless steel pump body and motor support
💧 Internal ejector
💧 Motor cooling ensured by design of fan guard
💧 Installation service available across Canada contact CLEANFLO WATER TECHNOLOGIES to find your local installer.

Advantages:

💧 Ability also to handle water containing gas
💧 Structure strength and flexibility
💧 Head up to 62 metres
💧 Optimal motor cooling

Benefits:

💧 Ability to operate also in the presence of air bubbles and small quantities of sand
💧 Increased safety
💧 High suction capacity
💧 Prevention of malfunctions and maintenance of motor efficiency
💧 Standardization of components enables optimal spare parts management

Downloads

Technical Specs:

download

Installation:

download

Sales Brochure:

download





Additional information

Weight 13 kg
Dimensions 50 × 40 × 30 cm
