DAB Diver 6 Submersible Pump

Description

The DAB 6” multi-impeller submersible pump for clean water is designed for pressurization, rainwater re-use, gardening, and irrigation in residential building services. This pump is ideal for use in rainwater recovery systems and for increasing water pressure. Available as an automatic model, it features a float switch for protection against dry running without the need for a control panel. The pump includes a built-in starting capacitor and the motor has integrated overheating protection. It is equipped with a stainless steel debris filter, a non-return valve, and a 49 ft (15 m) power cable with a power plug. The pump has been renewed to further increase reliability and ergonomics, with a completely redesigned handle. It is supplied as standard with a four-section step fitting and a 1″ M/F che

Max. flow rate: From 4.4 to 23.8 GPM(1 m3/h to 5,4 m3/h)

Max. head: 151 ft (46 m)

P2 Power range: from 1/2 to 1 Hp (0.4 kW up to 0.71 kW) single-phase

Max. immersion depth: 39 ft (12 m)
