NSF 55 Certified, 12 VDC, UV System Only (2.2 GPM @ 40mJ)

Description

NSF 55 Certified, 12 VDC, UV System Only (2.2 GPM @ 40mJ) Key Features:

💧 Versatile Power Supply: The BLACKCOMB 12 volt DC series is the ideal solution for areas without reliable AC power, ensuring that you receive top-notch UV water treatment regardless of your power supply limitations.

💧 Continuous Monitoring: With a true 254nm Teflon® based UV sensor, this series provides continuous monitoring, displaying UV system performance on an optional color screen (available on 5.1 systems). Diagnostics, system status, warnings, and QR codes can also be easily accessed for comprehensive system insight.

💧 Plug-and-Play Expandability: The integral expandability port allows for effortless plug-and-play options, such as adding a 4-20mA output or a solenoid valve. This adaptability ensures that your system can evolve with your needs.

💧 Intelligent User Interface: Experience ease of use with the color user interface, providing clear visuals of UV intensity, remaining lamp life, and any error or fault codes. A full system diagnostic on start-up adds an extra layer of confidence in the system’s reliability.

💧 Smart QR Code Integration: Access lamp change information and instructional videos seamlessly with incorporated QR codes, offering convenient web access for essential system insights.

💧 Future-Proof Design: The controller, a constant current electronic power source, is housed in a splash-proof case and comes standard with a “future-proof” expandability port. This ensures your system is ready for future upgrades or options, keeping you ahead in technology.

💧 NSF Class A Certification: The BLACKCOMB 6.1 series proudly holds NSF Class A certification, meeting the rigorous standards set by NSF (National Sanitation Foundation). For more information on NSF, please visit their site at www.nsf.org.

Upgrade to LUMINOR’s BLACKCOMB 6.1 UV Water Treatment Systems for uncompromising water purity, advanced technology, and the peace of mind that comes with continuous monitoring. Choose excellence, choose LUMINOR.



 Specs:

NSF Class A Flow Rate (30 mJ/cm² @ 95% UVT)	3 gpm 11.4 lpm 0.70 m³/hr
NSF Class A Flow Rate (40 mJ/cm² @ 95% UVT)	2.4 gpm 9.1 lpm 0.5 m³/hr
Port Size	½” MNPT
Electrical	12VDC / 2.5A Max
Plug Type	DC Power cable, wire leads (255050)
Lamp Watts	15
Power (watts)	20
Chamber Material	304 Stainless Steel, A249 Pressure Rated Tubing
Replacement Lamp	RL-290
Replacement Sleeve	RQ-290
Reactor Dimensions	2.5 x 14.3″ (6.4 x 36.4 cm)
Controller Dimensions	6.8 x 3.6 x 4″ (172 x 92 x 102 mm)
Maximum Operating Pressure	0.7-10.3 bar (10-150 psi)
Operating Temperature Range	2-40° C (36-104° F)
UV Monitor	YES on all “LB6” models. Upgrade available for “LB5” models (RS-B2.5)
Solenoid Output	YES (optional solenoid module (MOD-SOL) sold separately
Dry Contacts	YES (remote alarm module (MOD-RAM) sold separately)
4-20 mA Output	YES (4-20mA module (MOD-420) sold separately
Temp. Management Valve	130031
Cooling Fan	No
Lamp Change Reminder (audible & visual)	Yes
Lamp-Out Indicator (audible & visual)	Yes
Shipping Weight	3.6 kg (7.9 lbs)
