Commercial UV System Only (180 GPM @ 30 mJ)

Description

Commercial UV System Only Key Features:

💧 Upgradeable Design: The RAINIER 5.0 model is engineered for the future. The integral UV sensor port allows for the seamless addition of an optional UV sensor module at a later date, ensuring your system stays ahead of evolving water treatment standards.

💧 Visual Assurance: For situations where a monitor is unnecessary, the system features an integral visual glow plug, providing an extra layer of assurance that your UV lamp is consistently illuminated.

💧 Premium Build: Crafted from high-grade 316L stainless steel, the pressure vessels adhere to rigorous ASME standards, ensuring robustness and longevity. The bayonet-style lamp connector facilitates tool-free lamp changes, making maintenance hassle-free.

💧 Advanced Lamp Technology: RAINIER incorporates low-pressure, amalgam (LP-AM) coated UV lamps, offering enhanced power density and a consistent output over an impressive 12,000-hour rated life. This ensures a reliable and long-lasting water treatment solution.

💧 Intelligent Monitoring: Stay in control with the integral LED display providing real-time information on remaining lamp life, total running hours, audible and visual lamp failure alerts, remote-on functionality, and solenoid readiness. This comprehensive monitoring system ensures optimal system performance and timely maintenance.

💧 Versatile Water Treatment: Whether you’re dealing with hot or cold water, RAINIER has you covered. Capable of handling low UV transmittance (UVT) levels as low as 50% and effectively reducing Total Organic Carbon (TOC) in industrial-grade waters, this system is a versatile solution for diverse applications.

Elevate your commercial water treatment to unprecedented levels with LUMINOR RAINIER 5.0. Choose reliability, efficiency, and adaptability for your water purification needs. Opt for RAINIER – where innovation meets excellence.

Specs:

Flow Rate 30 mJ/cm² @ 95% UVT (Industry Std.)	180 gpm 681 lpm 40.9 m³/hr
Alternate Flow Rate 16 mJ/cm² @ 95% UVT (US Public Health)	377 gpm 1276 lpm 76.5 m³/hr
Alternate Flow Rate 40 mJ/cm² @ 95% UVT	135 gpm 511 lpm 30.7 m³/hr
Port Size	3″ MNPT
Electrical	230V / 50-60Hz
Plug Type	North American NEMA 6/15
Lamp Watts	344
Power (watts)	360
Chamber Material	316L Stainless Steel, A249 Pressure Rated Tubing, Polished & Passivated
Replacement Lamp	RL-843A (2 required)
Replacement Sleeve	RQ-843 (2 required)
Reactor Dimensions	6×40.6×7.9″ 15x103x20cm
Controller Dimensions	11.8 x 7.9 x 6.3″ (30.0 x 20.1 x 16.0 cm)
Maximum Operating Pressure	10 bar (150 psi)
Operating Temperature Range	2-40° C (36-104° F)
UV Monitor	Upgradeable, includes visual glow plug
Remote On	Yes, with optional 210010 cable
Dry Contacts (Solenoid Ready)	Yes, with optional 210010 cable
4-20 mA Output	Yes, with optional 210010 cable
Lamp Change Reminder (audible & visual)	Yes
Lamp-Out Indicator (audible & visual)	Yes
Shipping Weight	Call Manufacturer
