Commercial UV System Only (85 GPM @ 30 mJ)

Description

Commercial UV System Key Features:

💧 Future-Ready Design: The RAINIER 5.0 model is engineered for adaptability. The integral UV sensor port allows for the addition of an optional UV sensor module in the future, ensuring your system can evolve with your needs.

💧 Visual Assurance: For instances where a monitor is not required, the integral visual glow plug provides an extra layer of assurance by visually confirming the illumination of your UV lamp. This feature simplifies maintenance and enhances reliability.

💧 Premium Construction: Crafted from robust 316L stainless steel, the pressure vessels adhere to ASME standards, ensuring durability and reliability in commercial settings. The bayonet style lamp connector facilitates easy tool-free lamp changes, minimizing downtime.

💧 Advanced Lamp Technology: RAINIER incorporates low-pressure, amalgam (LP-AM) coated UV lamps, offering increased power density and a consistent output over an impressive 12,000-hour rated life. This ensures sustained performance and longevity.

💧 Comprehensive Monitoring: Stay informed with the integral LED display, providing real-time data on remaining lamp life, total running hours, audible and visual lamp failure, remote-on, and solenoid readiness. This comprehensive monitoring system ensures optimal performance at all times.

💧 Versatile Application: RAINIER is designed to address water treatment challenges in both hot and cold water environments, accommodating UVT levels as low as 50%. Whether you’re dealing with industrial-grade waters or aiming to reduce TOC, RAINIER has you covered.

Upgrade your commercial water treatment to the next level with LUMINOR’s RAINIER 5.0. Experience reliability, efficiency, and the flexibility to adapt to evolving water treatment needs. Choose LUMINOR for water treatment solutions that exceed expectations.



 Specs:

Flow Rate 30 mJ/cm² @ 95% UVT (Industry Std.)	85 gpm 322 lpm 19.3 m³/hr
Alternate Flow Rate 16 mJ/cm² @ 95% UVT (US Public Health)	167 gpm 632 lpm 37.9 m³/hr
Alternate Flow Rate 40 mJ/cm² @ 95% UVT	57 gpm 216 lpm 12.9 m³/hr
Port Size	2” MNPT
Electrical	230V / 50-60Hz
Plug Type	North American NEMA 6/15
Lamp Watts	207
Power (watts)	220
Chamber Material	316L Stainless Steel, A249 Pressure Rated Tubing, Polished & Passivated
Replacement Lamp	RL-1000A
Replacement Sleeve	RQ-1000
Reactor Dimensions	4×46.8×5.6″ 10x119x14cm
Controller Dimensions	11.8 x 7.9 x 6.3″ (30.0 x 20.1 x 16.0 cm)
Maximum Operating Pressure	10 bar (150 psi)
Operating Temperature Range	2-40° C (36-104° F)
UV Monitor	Upgradeable, includes visual glow plug
Remote On	Yes, with optional 210010 cable
Dry Contacts (Solenoid Ready)	Yes, with optional 210010 cable
4-20 mA Output	Yes, with optional 210010 cable
Lamp Change Reminder (audible & visual)	Yes
Lamp-Out Indicator (audible & visual)	Yes
Shipping Weight	Call Manufacturer
